Tech Spec

• Panel

  Panel spec

  Screen Size	55
  Brightness	400
  Resolution	1,920 x 1,080 (FHD)

• Connectivity

  Connectivity spec

  Input	HDMI (1+1), DP (1+1), DVI-D (1+1)
  Output	Audio (1+1)
  External Control	RS232C (1+1), RJ45 (1+1), IR Receiver, USB 2.0 (2), USB 3.0 (2)

• Physical Specification

  Physical Specification spec

  Bezel Width	2, 2, 2, 2 mm (U, B, L, R *Off-bezel)
  Weight (Head)	21 kg
  Dimension (W x H x D)	Head : 1,227.6 x 702.7 x 7.94 mm (Edge depth : 8.94 mm), Signage Box : 470.1 x 402.8 x 75 mm

• Environment Conditions

  Environment Conditions spec

  Operation Temperature	0°C to 40°C
  Operation Humidity	10 % to 80 %

• Power

  Power spec

  Power Supply	100-240V~, 50/60Hz
  Power Type	Built-In Power

• Power Consumption

  Power Consumption spec

  Typ.	375 W
  DPM	3 W
  Power off	0.5 W

• Standard (Certification)

  Standard (Certification) spec

  Safety	UL / cUL / CB / TUV / KC
  EMC	FCC Class
  ErP / Energy Star	Yes / NA

• Media Player Compatibility

  Media Player Compatibility spec

  OPS type compatible	Yes
  External Media player Attatchable	Yes

• Software Compatibility

  Software Compatibility spec

  SuperSign-c	Yes
  SuperSign-w lite	Yes

• Accessory

  Accessory spec

  Basic	Remote Controller (included 2ea batteries), Power Cord, QSG, Mini HDMI Cable (3M x 2ea, for connection between head and signage box), Power Hanness Cable (3M x 2ea, for connection between head and signage box), Regulation Book, Phone to RS232C Gender, Jack Cover, Signage Box Mounting Bracket
  Optional	OPS Kit (KT-OPSA), Fixed Ceiling Mount Kit (ACC-CF-EH5C), Rotational Ceiling Mount Kit (ACC-CR-EH5C), Wall Mount Kit (ACC-W-EH5C), Stand Kit 1 (ACC-S-EH5C), Stand Kit 2 (ACC-S1-EH5C), Signage Box Cover (ACC-C-EH5C)
