55SM5KD

SM5KD Series

Global  Share

Key Feature

  • Brightness(Typ.): 450 cd/m²
  • Bezel : T/L/R 11.9 mm, B 18.0 mm
  • Depth : 54 mm
  • Interface : HDMI(2), DVI, DP, RGB, RJ45, IR, RS232C, USB
  • Built-in Speaker : 10W + 10W
1530840297115_38323

Quad Core SoC with webOS

High Performance Smart Platform

Quad Core SoC (System-on-Chip) executes several tasks at once with smooth content playback without a media player. webOS smart signage platform enhances user convenience with intuitive UI and simple development tools.
1530840336943_10271

Integrated CMS

Easy Contents Management

Embedded CMS (Content Management System) allows users to edit and play content, and create playlists, all without a seperate PC. It's a one-stop solution that lets users manage signage simply, and effectively.
1530840374662_55833

GUI for B2B & EZ Setting

Enhanced Usability

A B2B dedicated GUI for portrait and long range environment modes provides convenient user management. With the 'EZ setting', users get integrated management of signage special features through a unifying access point.
1530840409215_37026

Video Streaming

Real-time Streaming

Various types of IP video streaming protocols such as RTSP/RTP/HLS and UDP Multicast are supported for real-time content streaming. It is easy to manage content as it is free from capacity limits for content playback, and provides live broadcasts.
* Image is for illustration-purposes only.
1530840459810_75521

Gapless Playback

Seamless Content Playback

During playback of diverse content such as videos, images, and HTML, enjoy seamless transition between screens with no black screen gaps with webOS.
1530840498536_65468

PBP/PIP

Multiple Screen Composition

PBP (Picture-By-Picture) and PIP (Picture-In-Picture) enables up to two divided split screens in landscape or portrait display format enabling users to more flexibly allocate space for each content source.
1530840536931_01851

Detachable Logo & Built-in Speaker

Suited for Industrial Design

The detachable logo allows for installation in the desired orientation: landscape or portrait mode. Also, sounds can be played from built-in speakers, giving advertisements greater impact.
1530840583258_24687

Wireless Solution

Content Sharing

Mirroring among devices is more convenient on a Wi-Fi network.
1530840615482_43573

Wireless Solutions

Real-time Promotion

With Beacon and Bluetooth Low Energy (BLE), retail stores can provide coupons and information in real-time.
1530840650275_88155

Support for Network Protocol

HTTPS

With support for the HTTPS (Hypertext Transfer Protocol over Secure Socket Layer) protocol, communication between the server and signage is more secure.
1530840686173_57510

Support for Network Protocol

Proxy Server

Web access speed and security can be improved by supporting proxy server. Managers can not only block unwanted websites, but also quickly access to resources using caches.
1530840716710_57388

Conformal Coating

The product can be often unavoidably exposed to dust and water during maintenance. Conformal coating on major circuit board eliminates such troubles by protecting it against dust, iron powder, humidity, etc.

Tech Spec

  • Panel

    Panel spec
    Screen Size 55
    Resolution 1,920 x 1,080 (FHD)
    Brightness (Typ., cd/m²) 450
  • Connectivity

    Connectivity spec
    Input HDMI (2), DP, DVI-D, RGB, Audio, USB 3.0
    Output DP, Audio
    External Control RS232C in/out, RJ in, IR Receiver, Pixel Sensor
  • Physical Specification

    Physical Specification spec
    Bezel Width 11.9 mm (T/R/L), 18 mm (B)
    Monitor Dimension (W x H x D) 1,238 x 714.9 x 54 mm
    Weight (Head) 17.5 kg
    VESA™ Standard Mount Interface 300 x 300
  • Environment Conditions

    Environment Conditions spec
    Operation Temperature 0°C to 40°C
    Operation Humidity 10 % to 80 %
  • Power

    Power spec
    Power Supply 100-240 V~, 50/60 Hz
    Power Type Built-In Power
  • Power Consumption

    Power Consumption spec
    Typ. 100 W
    Smart Energy Saving 70 W
  • Standard (Certification)

    Standard (Certification) spec
    Safety UL / cUL / CB / TUV / KC
    EMC FCC Class
    ErP / Energy Star NA / Yes (Energy Star 7.0)
  • Media Player Compatibility

    Media Player Compatibility spec
    OPS type compatible Yes
    External Media player Attatchable Yes (MP500/MP700)
  • Software Compatibility

    Software Compatibility spec
    Content Management Software SuperSign Premium
    Control and Monitoring Software SuperSign Link
  • Accessory

    Accessory spec
    Basic Remote Controller (included 2ea batteries), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, Memory cover
    Optional Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100), Touch Overlay (KT-T550)
