55VH7B

VH7B Series

Global  Share

Key Feature

  • webOS 2.0
  • Quad Core SoC built-in
  • Brightness : 700cd/m²
  • Bezel : Less than 2.0mm (B-to-B)
  • SoC Based Sync-Playback
  • Image Gap Reduction
1531362680675_22628

Narrowest Bezel

Borderless design with its 0.9mm even panel bezel* enables immersive and seamless viewing experiences on assembled video wall screens.
1531362714767_87518

Uniform Brightness

LG’s LED backlight technology guarantees high uniformity in brightness to ensure a clear picture. On other screens, certain spots may appear darker than others, but the new VH7B generates high visibility and a consistent brightness across the whole screen.
1531362746609_30736

Clear Viewing Angle

The VH7B ensures clear picture quality even when installed in stacks of more than four. This is very favorable for the quantity of video walls installed in large spaces.
1531362791013_37836

Shine Out

The VH7B is the perfect fit for window displays because it reflects sunlight for better visibility and a clearer image than conventional panels.
1531362826299_44266

LAN Daisy Chain Performance

A LAN daisy chain allows you to execute commands to control and monitor the screens and even update their firmware.
ID_QRcode_M03_1461223923273

LG C-Display
Customer App

Download and experience the Video Wall Configurator as a simulation tool for your Video Wall installation.

Tech Spec

  • Panel

    Panel spec
    Screen Size 55
    Resolution 1,920 x 1,080 (FHD)
    Brightness (Typ.,Module) 700
  • Physical Specification

    Physical Specification spec
    Monitor Dimension (W x H x D) 1,211.4mm X 682.2mm X 86.5mm
    Weight (Head) 18.6kg
    VESA™ Standard Mount Interface 600mm x 400mm
    Bezel Width (B to B) 0.9 (top/bottom/left/right even bezel) mm (1.8mm) * B to B : Panel Bezel + Panel Bezel
  • Media Player Compatibility

    Media Player Compatibility spec
    External Media player Attatchable Yes (MP500/MP700)
    OPS type compatible Yes
  • Software Compatibility

    Software Compatibility spec
    SuperSign-c Yes
    SuperSign-w lite Yes
  • Accessory

    Accessory spec
    Basic Remote Controller, Power cable, DVI Cable, Manual, IR Receiver, RS-232C Cable, Guide Bracket, Screw
    Optional Wall Mount (Landscape : WM-L640V, Portrait : WM-P640V), OPS Kit (KT-OPSA), HD Base T (EB-B100)
  • Connectivity - Output

    Connectivity - Output spec
    External Control (RS232C OUT) Yes (1)
    Externel Speaker Out -
    Audio Out Yes (1)
    DP Out Yes (1), DP1.2a/HDCP1.3
    External Control (RJ45) Yes (1)
  • General Features

    General Features spec
    Region Global
  • Connectivity - Intput

    Connectivity - Intput spec
    External Control (RJ45) Yes (1)
    DP Yes (1), DP1.2a/HDCP1.3
    External Control (RS232C IN) Yes (1)
    DVI-D Yes (1), HDCP2.2
    External Control (IR receiver) Yes (1)
    Analog (RGB) Yes (1)
    External Control (Pixel Sensor) -
    HDMI Yes (1), HDMI /HDCP2.2
    Audio In Yes (1)
    SD Card (SDHC/Full Size) -
    USB (USB3.0/USB2.0) Yes (1) / Yes (1)

Recently Viewed

Product design, features and specifications are subject to change without notice and may also differ based on your region of purchase.
Screen images are simulated and/or dramatized. Some features in videos may not be available on all models. Please refer to the TECHNICAL SPECIFICATIONS tab for a complete list of features by model.
