Narrowest BezelBorderless design with its 0.9mm even panel bezel* enables immersive and seamless viewing experiences on assembled video wall screens.
Uniform BrightnessLG’s LED backlight technology guarantees high uniformity in brightness to ensure a clear picture. On other screens, certain spots may appear darker than others, but the new VH7B generates high visibility and a consistent brightness across the whole screen.
Clear Viewing AngleThe VH7B ensures clear picture quality even when installed in stacks of more than four. This is very favorable for the quantity of video walls installed in large spaces.
Shine OutThe VH7B is the perfect fit for window displays because it reflects sunlight for better visibility and a clearer image than conventional panels.
LAN Daisy Chain PerformanceA LAN daisy chain allows you to execute commands to control and monitor the screens and even update their firmware.
Download and experience the Video Wall Configurator as a simulation tool for your Video Wall installation.
Panel spec Screen Size 55 Resolution 1,920 x 1,080 (FHD) Brightness (Typ.,Module) 700
Physical Specification spec Monitor Dimension (W x H x D) 1,211.4mm X 682.2mm X 86.5mm Weight (Head) 18.6kg VESA™ Standard Mount Interface 600mm x 400mm Bezel Width (B to B) 0.9 (top/bottom/left/right even bezel) mm (1.8mm) * B to B : Panel Bezel + Panel Bezel
Media Player Compatibility
Media Player Compatibility spec OPS type compatible Yes External Media player Attatchable Yes (MP500/MP700)
Software Compatibility spec SuperSign-c Yes SuperSign-w lite Yes
Accessory spec Basic Remote Controller, Power cable, DVI Cable, Manual, IR Receiver, RS-232C Cable, Guide Bracket, Screw Optional Wall Mount (Landscape : WM-L640V, Portrait : WM-P640V), OPS Kit (KT-OPSA), HD Base T (EB-B100)
Connectivity - Output
Connectivity - Output spec External Control (RS232C OUT) Yes (1) Externel Speaker Out - Audio Out Yes (1) DP Out Yes (1), DP1.2a/HDCP1.3 External Control (RJ45) Yes (1)
General Features spec Region Global
Connectivity - Intput
Connectivity - Intput spec External Control (RJ45) Yes (1) DP Yes (1), DP1.2a/HDCP1.3 External Control (RS232C IN) Yes (1) DVI-D Yes (1), HDCP2.2 External Control (IR receiver) Yes (1) Analog (RGB) Yes (1) External Control (Pixel Sensor) - HDMI Yes (1), HDMI /HDCP2.2 Audio In Yes (1) SD Card (SDHC/Full Size) - USB (USB3.0/USB2.0) Yes (1) / Yes (1)
Screen images are simulated and/or dramatized. Some features in videos may not be available on all models. Please refer to the TECHNICAL SPECIFICATIONS tab for a complete list of features by model.
